Optical IN-DISPLAY FINGERPRINT SENSOR^TM

Goodix is the inventor and market leader of optical IN-DISPLAY FINGERPRINT SENSOR™. By transforming a defined area of a display into a fingerprint "button" for various smart devices with AMOLED screens, the solution leads the evolution of bezel-less design. Goodix owned self-developed core technologies, ranging from IC design, software & algorithms, manufacturing & processing to testing solutions, which enables it to provide global customers with turnkey hardware and software solutions featuring both high performance and high quality.

Ultra-Thin Optical IN-DISPLAY FINGERPRINT SENSOR™

Based on an optical collimator, fingerprint module as thin as 0.26 mm

Can be assembled on the middle frame by overlapping with the battery, no need to attach to the screen

Enables extra internal space for a larger capacity battery and improves the linear motor performance for a mobile phone

Allows for more flexible and more ergonomic designs of unlocking area

Goodix invented, extensively used in flagship models of renowned mobile phone brands

Lens-Type Optical IN-DISPLAY FINGERPRINT SENSOR™

Applies the micro-focus technology based on the pinhole effect, fingerprint module as thin as only 3.2 mm to 4.2 mm

Matching latency as fast as only 75 ms

Can be assembled on the middle frame and placed side by side with the battery

Goodix invented, widely used in smart devices such as mid- and high-end mobile phones and tablets

Part Number	Status	Applications	Product Type	FOV	Module Size	Supply Voltage	Interface
GW9558	Active	Under AMOLED Display	Optical Lens Type	6.5 mm * 6 .5 mm	7.25 mm * 4.8 mm * 4.2 mm	3.1~3.6 V	SPI
GW9578	Active	Under AMOLED Display	Optical Lens Type	6.5 mm * 6.5 mm	5.84 mm * 4.63 mm * 4.2 mm	3.1~3.6 V	SPI
GW9588	Active	Under AMOLED Display	Optical Lens Type	5.5 mm * 5.5 mm ~ 6.5 mm * 6.5 mm	5.84 mm * 4.63 mm * 3.2 mm ~ 5.84 mm * 4.63 mm * 3.9 mm	2.7~3.6 V	SPI
GW9628	Active	Under AMOLED Display	Optical Ultra-thin	6 mm * 6 mm	14.3 mm * 12.84 mm * 0.28 mm	2.6~3.6 V	SPI
GW9668	Active	Under AMOLED Display	Optical Ultra-thin	5 mm * 5 mm	14.3 mm * 12.84 mm * 0.28 mm	2.6~3.6 V	SPI
