Home > Sensors > Health Sensors

Industry-leading Health Sensors Featuring High Precision,
Low Power Consumption, and High Integration

Overview
Product Series
Product Video
Product Details
Get Started
Why Goodix

Overview

Goodix's health sensors product family combines a series of integrated and discrete products. Our optical modules enable Photo Plethysmo Graphy (PPG), supporting heart rate(HR), heart rate variability (HRV) and oxygen saturation (SpO2) detections, while the analog front-end (AFE) can provide high-precision and low-power consumption measurements including electrocardiogram (ECG), bioelectrical impedance analysis (BIA), and electrodermal activity (EDA) to help users achieve more vital signs monitoring. Goodix offers customers with hardware, software, mechanical and optical design guidelines, as well as algorithms to accelerate the time to market of customer products.

Product Series

Optical Module Highly-integrated optical packaging module, stacked with photodiode(PD), supporting physiological indexes detecting, such as HR, HRV and SpO2.
GH3011
PPG AFE High performance PPG analog front-end, supporting physiological indexes detecting, such as HR, HRV and SpO2.
GH3030 GH3020 GH3026
Multi-modal AFE High performance multi-modal analog front-end, supporting physiological indexes detecting, such as HR, HRV, SpO2, ECG, Bio-Z and temperature.
GH3300 GH3310 GH3311 GH3220 GH3220T GH3026T

Product Video

Product Details

Product Type P.N. PPG TX PPG RX ECG Bio-Z Temperature Force detecting Interface Package Size(mm)
LED Channels Max LED current AFE channels PD channels ECG channels BIA channels EDA channels RESP channels NTC channels Force detecting channels
Optical Module GH3011 3 100 mA 1 1 / / / / / / IIC/SPI LGA 19 3 * 4 * 0.8
PPG AFE GH3030 16 200 mA * 4 4 8 Single/ 4 Diff / / / / / / IIC/SPI WLCSP-49 2.645 * 2.645 * 0.5
GH3020 8 200 mA * 2 4 8 Single/ 4 Diff / / / / / / IIC/SPI WLCSP-42 2.6 * 2.9 * 0.46
GH3026 8 200 mA * 2 2 8 Single/ 4 Diff / / / / / / IIC/SPI WLCSP-42 2.6 * 2.9 * 0.46
Multi-modal AFE GH3300 16 200 mA * 4 4 8 Single/ 4 Diff 1( DC or AC) 1 1 1 4 / IIC/SPI WLCSP-49 2.645 * 2.645 * 0.5
GH3310 16 200 mA * 4 4 8 Single/ 4 Diff 1( DC or AC) / 1 / 4 / IIC/SPI WLCSP-49 2.645 * 2.645 * 0.5
GH3311 16 200 mA * 4 4 8 Single/ 4 Diff / 1 1 / 4 / IIC/SPI WLCSP-49 2.645 * 2.645 * 0.5
GH3220 8 200 mA * 2 4 8 Single/ 4 Diff 1 / / / / / IIC/SPI WLCSP-42 2.6 * 2.9 * 0.46
GH3220T 8 200 mA * 2 4 5 Single/ 2 Diff 1 / / / 3 / IIC/SPI WLCSP-42 2.6 * 2.9 * 0.46
GH3026T 8 200 mA * 2 2 8 Single/ 4 Diff / / / / 4 / IIC/SPI WLCSP-42 2.6 * 2.9 * 0.46
GH7530 / / / / 3 / / 1 2 / IIC/SPI QFN48 6 * 6
GH7339 4 200 mA * 4 1 4 Single/ 2 Diff 3 / / 1 2 / IIC/SPI QFN48 6 * 6
GH3500 / / / / 2 1 1 / 4 2 IIC/SPI QFN48 6 * 6
GH3400 / / / / / 1 1 / 4 2 IIC/SPI QFN48 6 * 6

Get Started

We provide a wealth of development resources for
your reference. In addition, comprehensive technical support
helps you quickly start product development.

SDKs

  • Abundant resources of SDKs
  • Provide with driver Lib, algorithm
    Lib, and relevant documents

Hardware resources

  • EVKs for chip verification and
    performance testing
  • Mass production test board
    for module test and completed
    product test

Development tools

  • Easy-to-use Apps
  • EVK software tools

Documents

  • Datasheets and Application notes
  • Reference schematics, BOM, and structure design

Mass production test

  • Documents for mass production
  • Manufacturing guide
  • Software tools for PC platform

Supporting

  • Remote or on-site supporting
  • On-line supporting

Why Goodix?

Extensive Product Range

  • A wide range of high-performance and cost-effective models at your choice

Turnkey Solutions

  • Ready-to-go solutions with chips and core algorithms

Leading Performance

  • Industry-leading performance for precise and reliable measurement

Reliable Delivery

  • Large-scale mass production experience for stable and timely delivery
