Enabling a Wide Range of NB-IoT Applications with OpenCPU

Overview

Narrowband Internet of Things (NB-IoT) is a low-power wide-area network (LPWAN) technology based on cellular communication. Featuring ultra-low-power consumption, wide-range coverage, high-capacity connectivity and high security, it is a significant part of future-oriented 5G standard systems. Backed by a wide range of platform solutions with uncompromised security, NB-IoT is enabling billions of connections among thousands of applications. Featuring secure and ultra-low-power OpenCPU, our industry-leading NB-IoT System-on-Chip (SoC) GR851x series stands out with competitive and cost-effective single-chip solutions for applications in smart meters, asset management, smoke detectors, smart bands, and other NB-IoT applications.

Product Video

Product Details

Model

Status

AP

RAM

Flash

I/O

Package

Crystal Oscillator

Operating Temperature

GR8513NMBIN

Active

Cortex®-M4F 69 MHz

128 KB

4 MB

61

BGA121L

26M TCXO or 26M DCXO / THX

-40°C ~ +85°C

GR8513JMNIN

Active

Cortex®-M4F 69 MHz

128 KB

4 MB

14

QFN58L

Only 26M TCXO

-40°C ~ +85°C

GR8513JMNID

Active

Cortex®-M4F 69 MHz

128 KB

4 MB

14

QFN58L

Only 26M DCXO / THX

-40°C ~ +85°C

Why Goodix?

Low Power OpenCPU Solution
  • Average current at 9.4 uA (smart meter power model)

  • Decoupling AP & CP

  • Up to 56 GPIO

  • Increment SDK, Segmental DFOTA

  • TX @ 23 dBm: 230.9 mA (measured on RF3628 PA), eDRX @ 655s: 6.0 uA

Ultra Stability in Low Level Coverage
  • RX sensitivity: -117 dBm

  • High success rate for connection in ultra-low level coverage network

Uncompromised Security
  • Deutsche Telekom NuSIM / TuvIT Lab Certificated

  • OSCCA Level 2 capability

Comprehensive Support
  • Easy to use development tool and MP tool

  • Rich reference designs

  • Strong AE / FAE team
